Despite the tranquil and apparently unchanging beauty of a starry night, the Universe is far from being a quiet place. Stars are being born and dying in an endless cycle, and sometimes the death of a star can create a vista of unequalled beauty as material is blasted out into space to form strange structures in the sky.

This oddly shaped cloud, which is also known as NGC 2736, is a small part of a supernova remnant in the southern constellation of Vela (The Sails). These glowing filaments were created by the violent death of a star that took place about 11 000 years ago. The brightest part resembles a pencil; hence the name, but the whole structure looks rather more like a traditional witch’s broom.

The Vela supernova remnant is an expanding shell of gas that originated from the supernova explosion. Initially the shock wave was moving at millions of kilometres per hour, but as it expanded through space it ploughed through the gas between the stars, which has slowed it considerably and created strangely shaped folds of nebulosity. The Pencil Nebula is the brightest part of this huge shell.

This new image shows large, wispy filamentary structures, smaller bright knots of gas and patches of diffuse gas. The nebula's luminous appearance comes from dense gas regions that have been struck by the supernova shock wave. As the shock wave travels through space, it rams into the interstellar material. At first, the gas was heated to millions of degrees, but it then subsequently cooled down and is still giving off the faint glow that was captured in this image (ESO).

This field also contains RCW38, visible at the bottom of the image that is an embedded cluster located about 5,500 light years away. The cluster is composed of several short-lived massive stars. Many of these stars will go on to explode as supernovae.
